Waterproof cable connector for safe wire connection
This waterproof cable connector is an ideal solution for quick and safe connection of two- and three-core wires in demanding conditions. Thanks to the terminal block with self-clamping terminals, it allows easy and quick installation without the need for tools, which significantly simplifies installation even in the field. The connector is designed for a maximum voltage of 450 V AC and a current of up to 16 A, ensuring reliable operation in a wide range of applications. With three contacts and the ability to connect cables with a diameter of 5–9 mm and conductor cross-sections of 0.5–2.5 mm², it is suitable for most common electrical installations.

Resistance to water and extreme conditions
The connector meets the IP68 protection rating, which means it is fully protected against dust ingress and can withstand immersion in water up to a depth of 3 m for a maximum of 48 hours. This makes it suitable for use outdoors, underground, or in areas with high humidity. The T60 operating temperature ensures reliability even at higher temperatures. Compact dimensions of 80 x 24 mm allow for easy installation even in confined spaces, which you will appreciate when working in distribution boxes or underground.

• waterproof cable for connecting two and three-wire wires
• the gland includes a terminal block with self-tightening clamps that enable quick assembly without the use of additional tools
• number of contacts: 3
• maximum voltage: 450V AC
• maximum current: 16A
• waterproof: IP68
• cable diameter: 5-9mm
• conductor cross-section: 0.5-2.5mm2
• maximum immersion depth: 3m, max. 48 hours
• operating temperature: T60
• dimensions: 80 x 24mm
